Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well
Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well

Large Image :  Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well

Product Details:
Place of Origin: Hebei,China
Brand Name: Heng Yuan
Certification: ISO9000
Model Number: HY32503
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Moister-Barrier with each piece,110 pcs per 20 ft container
Delivery Time: 7-10 work days,according to the quantity
Payment Terms: L/C, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000pcs/Month
Detailed Product Description
Name: Water Well Screen Material: Low Carbon Galvanized
Diameter: 8-5/8" OD: 219 Mm
Slot Size: 1.0 Mm Length: 3000mm
Wire: 2.2*3.5mm Vee Wire Support Rod: ø3mm Round Wire
No. Of Rods: 48 PCS End Connection: 30mm Width Welded Rings
Weight: 40 KG/piece Package: Plastic Film
High Light:

219mm OD water well screen

,

galvanized water well screen

,

OD 219mm water well screen

Low Carbon Galvanized O.D 219mm Water Well Screen For Sand Control In Shallow Well



Water Well Screen Description:

Water well screen, also be named Johnson strainer,Johnson filter,wire wrapped screen, wound screen, water wire screen, It has been known as the world's leading manufacturer and provider of industrial filters since 1904.We provide screening solutions to almost every industry,including:



·Water Well

·Waste Water Treatment

.Water supply systems

·Coal & Mine

·Food Processors & Beverage Screens

·Environmental protection

·Refining & Petrochemical

·Architecture & Construction



Water Well Screen Specification:

Name Water Well Screen
Material Low Carbon Galvanized
Grade Q195
O.D 219 mm
Size 8-5/8"
Slot size 1.0mm
Length 3 m
End connection 30mm width welded rings
Wire size 2.2*3.5mm Vee wire (2.2 is the width and 3.5 is the height)
Support rod ø3.0mm round wire
Wire shape Vee-shaped



Water Well Screen Advantage:

1. Stop sand production

2. Avoid pump damage

3. Improve well efficiency

4. Improve pumping efficie

5. Profile wire wrapped around support rods

6. Continuous slot opening

7. Strong structure

8. Low comprehensive cost

9. Maximize water flow rate into the well

10.Reduce the abrasion of the pump

11.Extend the life span of wells

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 0

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 1

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 2

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 3

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 4

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 5

Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 6Low Carbon Galvanized 219mm OD Water Well Screen For Sand Control In Shallow Well 7
