Water Well Sand Control Screens With High Temperature Resistance

Large Image : Water Well Sand Control Screens With High Temperature Resistance

Product Details:

Place of Origin:	Hebei,China
Brand Name:	HengYuan
Certification:	ISO9001-2008
Model Number:	HY-147

Payment & Shipping Terms:

Minimum Order Quantity:	10 pcs
Price:	USD 100/PC
Packaging Details:	wooden boxes
Delivery Time:	10 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	2000 pcs/month

Contact Now

Detailed Product Description

Name:	Wound Screen/johnson Screen	Technique:	Electric Galvanized Welded/all Welded
Length:	Up To 6000mm	Wire:	1.52mm;23mm
Application:	Sand Control Filter Screen
Highlight:	johnson screen mesh , johnson screen pipe

Water Well Sand Control Screens With High Temperature Resistance

Product Specifications

Attribute	Value
Name	Wound screen/Johnson screen
Technique	Electric galvanized welded/all welded
Length	Up to 6000mm
Wire	1.5×2mm; 2×3mm
Application	Sand control filter screen

Product Description

Stainless Steel Water Well Screen / Well Pump Screen used in water wells with high temperature resistance and durability.

Material Options

302, 304, 304L, 316, 316L and other stainless steel wire and low carbon steel wire, galvanized iron wire, etc. Custom materials available upon request.

Construction & Features

Composed of support bars and sieve bars for structural integrity
Support bars available in round wire, triangular wire, or trapezoidal wire
Sieve bars feature V-shaped wire for precise gap sizing and high filtration accuracy
Firm structure with excellent high temperature and corrosion resistance
Long service life with reliable mechanical performance
Suitable for filtration of various media types

Technical Specifications

Material	SS304, SS304L, SS316, SS316L, SS321, Duplex, Hastelloy, etc
Length Range	Up to 6000mm
OD Range	3"-16"
Slot Range	20 micron to 3000 microns (Tolerance: ±5 micron)
Wedge Wire	0.5×1.5 \| 0.75×1.5 \| 1×2 \| 1.5×2.5 \| 2×3 \| 2×4 \| 3×5
Support Rod	1.5×2.5 2×3 \| 1.5×2.5 2×3 \| 1.5×2.5 2×3 \| 2×3 \| 3×5 \| 3×5 \| 3×5 4×6 5×8
Connection	Welded rings or Male/female threaded/coupling

Applications

Water filtration with deep well pumps and submersible pumps
Water treatment equipment and environmental applications
Seawater conversion to industrial and domestic water
Desalination treatment and water softening
Petrochemical industry for petroleum product filtration
Chemical acid and alkali liquid filtration
Alcohol and organic solution recycling

Note: All specifications can be customized according to customer requirements.

Manufactured by Hengyuan Hardware Netting Industry Product Co., Ltd located in Anping County, Hebei Province, China.

Specializing in stainless steel wire products including Johnson screens, water well screens, wedge wire screen pipes, and various filtration solutions.
