| Grade: | SS 304 / 316 L / 321 | Wire Size: | 63# /1.5*2.5 /1.5*2 / 1*2 |
|---|---|---|---|
| Support Rod: | 93# / 2*3 / 2.2*3.5 | Slot: | 0.15 Mm |
| End Connection: | Nothing | Inner Diameter: | 220 Mm |
| Usage: | Liquid Filter | Hole Shape: | Slot |
| Length: | 600 Mm | Filter Type: | From Inside To Outside |
| High Light: | slot 40 reverse wedge wire screen,wound cylinder reverse wedge wire screen,v wire screen filter wound cylinder |
||
Stainless Steel Reverse Slot 40 Wedge Wire Wound Screen Cylinder is manufactured with V-shaped profile wire which is spirally wound around a cage of longitudinal support rods. Each intersecting point of these wires is fusion welded. The pitch of winding gives different spacing between two adjacent turns of wire. This spacing gives passage for water to enter. The entire process is completed on fully computerized machines.
A continuous slot opening which significantly increases the available open area, thus providing greater access to the water bearing zone (the aquifer). A "V" shaped profile wire which avoids clogging and ensures an uninterrupted flow. A uniform and efficient well development due to the continuous slot opening. Reverse wound screen can be backwashed, less clogging and longer filter life
| Material | stainless steel 304, 304L, 316, 316L, 321, etc. |
| Tube diameter | 25 mm - 1500 mm |
| Tube length | 0.3 m, 0.6 m, 1 m, 2 m, 3 m, 6 m and 12 m. Special sizes can be customized |
| Slot size | 0.05 mm - 2.5 mm |
| Surface profile type | triangle wire |
| Support profile |
triangle wire, round wire, flat bar or wedge wire |
Reverse Wedge Wire Screen Application:
Architecture & Construction
Food & Beverage Screens
OEM Screen Components
Refining & Petrochemical
Waste Water Treatment
Water Well & Oil well
Coal & Mine
Chemical industry
Pharmacy
Food and beverage
Metallurgy
Coal mining
Environmental protectio
Reverse V Slot Wedge Wire Drum Screen is widely used in oil, gas and water wells for sand prevention and its application in chemical industry, environmental protection and other industries.
It is the most widely used filter screen in all kinds of oil, water resources recycling and resin collection.
The world's most advanced full wound welding process in the world is adopted by the Johnson Vee-shaped wire winding screen.
The special stainless steel trapezoid (wedge-shaped) wire winding is welded on a group of longitudinal support rods arranged in a round round arrangement, thus ensuring its strength and service life.
Due to the adoption of full program welding, not only the strict integrity of the product is ensured, but also the ideal gap size is formed. Compared with the commonly used welding technology in China, the full welded wedged wire winding screen tube, filter pipe, water cap, water distributor, resin trap and sieve plate have the characteristics of smooth tube surface, no production edge angle, no burr, uniform gap and no grease leakage.
From inside to outside. Wire, Inside; Support rod, Outside.
1. Wire is the length of the screen pipe;
2. Support rod is the length of the screen pipe.
The cross-section of the screen strip is trapezoidal, the slots at lower part is wider than that of upper part of the screen.
